Каталог
ЯпонияМодель
DYNAДвигатель
3 литра, дизельКузов
TRUCK (EXCLUDING DUMP TRUCK)Фрейм
BU22Трансмиссия
МКПП, 5 скоростей, на рулеОпции
DOUBLE CAB TRUCK (JUST LOW) BOARDING DECK M50 TYPE TRANSMISSION 06S WT IV3 ATP
Код
Описание
4103
переход к группе запчастей
42311
SHAFT, REAR AXLE
42311A
SEAL, OIL (FOR REAR AXLE SHAFT)
42321
GASKET, REAR AXLE SHAFT
42323
WASHER, CONE (FOR REAR AXLE SHAFT)
42403
DRUM SUB-ASSY, REAR BRAKE
42411A
PIN, STRAIGHT (FOR REAR AXLE HUB)
42411B
BOLT, STUD (FOR REAR AXLE HUB)
42411C
BEARING, TAPERED ROLLER (FOR REAR AXLE INNER BEARING)
42411D
BEARING, TAPERED ROLLER (FOR REAR AXLE OUTER BEARING)
42411E
SEAL, OIL (FOR REAR AXLE HUB)
42414
PLATE, REAR AXLE HUB
42419
SCREW, REAR AXLE BEARING LOCK NUT
42420
HUB (OR SHAFT) & BRAKE DRUM REAR AXLE, RH
42427
NUT, REAR AXLE BEARING LOCK
42428
PLATE, REAR AXLE LOCK NUT
42430
HUB (OR SHAFT) & BRAKE DRUM REAR AXLE, LH
42608
BOLT SUB-ASSY, REAR AXLE HUB, RH
42609
BOLT SUB-ASSY, REAR AXLE HUB, LH
42611E
BOLT, HUB (FOR REAR AXLE)
42631
BOLT, DOUBLE WHEEL STOP, RH
42632
BOLT, DOUBLE WHEEL STOP, LH
9017020005
Крепеж
9411041000
Крепеж
9411571600
Крепеж
9451201000
Крепеж
Код
Описание
4103
переход к группе запчастей
42311
SHAFT, REAR AXLE
42311A
SEAL, OIL (FOR REAR AXLE SHAFT)
42321
GASKET, REAR AXLE SHAFT
42323
WASHER, CONE (FOR REAR AXLE SHAFT)
42403
DRUM SUB-ASSY, REAR BRAKE
42411A
PIN, STRAIGHT (FOR REAR AXLE HUB)
42411B
BOLT, STUD (FOR REAR AXLE HUB)
42411C
BEARING, TAPERED ROLLER (FOR REAR AXLE INNER BEARING)
42411D
BEARING, TAPERED ROLLER (FOR REAR AXLE OUTER BEARING)
42411E
SEAL, OIL (FOR REAR AXLE HUB)
42414
PLATE, REAR AXLE HUB
42419
SCREW, REAR AXLE BEARING LOCK NUT
42420
HUB (OR SHAFT) & BRAKE DRUM REAR AXLE, RH
42427
NUT, REAR AXLE BEARING LOCK
42428
PLATE, REAR AXLE LOCK NUT
42430
HUB (OR SHAFT) & BRAKE DRUM REAR AXLE, LH
42441
DEFLECTOR, BRAKE DRUM OIL
42608
BOLT SUB-ASSY, REAR AXLE HUB, RH
42609
BOLT SUB-ASSY, REAR AXLE HUB, LH
42611E
BOLT, HUB (FOR REAR AXLE)
42631
BOLT, DOUBLE WHEEL STOP, RH
42632
BOLT, DOUBLE WHEEL STOP, LH
9411041000
Крепеж
9411571600
Крепеж
9451100600
Крепеж
9451201000
Крепеж
