POWER TAKE-OFF CASE & GEAR TOYOTA DYNA, 1983/02 - 1984/08, 3 литра, дизель, TRUCK (EXCLUDING DUMP TRUCK), BU22, МКПП, 5 скоростей, на руле

Каталог

Япония

Модель

DYNA

Двигатель

3 литра, дизель

Кузов

TRUCK (EXCLUDING DUMP TRUCK)

Фрейм

BU22

Трансмиссия

МКПП, 5 скоростей, на руле

Опции

DOUBLE CAB TRUCK (JUST LOW) BOARDING DECK M50 TYPE TRANSMISSION 06S WT IV3 ATP

Код

Описание

36610

POWER TAKE-OFF ASSY

36610A

BOLT, LOCK BALL (FOR POWER TAKE-OFF)

36610B

GASKET, SEAT (FOR POWER TAKE-OFF)

36610C

SPRING, GEAR SHIFT FORK LOCK BALL (FOR POWER TAKE-OFF)

36610D

BALL, GEAR SHIFT FORK LOCK (FOR POWER TAKE-OFF)

36610E

SEAL, OIL (FOR POWER TAKE-OFF)

36610F

PLUG, EXPANSION (FOR POWER TAKE-OFF)

36611

CASE, POWER TAKE-OFF

36611A

BOLT, STUD (FOR POWER TAKE-OFF CASE)

36611B

PLUG, STRAIGHT SCREW (FOR POWER TAKE-OFF CASE)

36621

RETAINER, POWER TAKE-OFF BEARING

36621A

SEAL, OIL (FOR POWER TAKE-OFF BEARING RETAINER)

36624

CAP, POWER TAKE-OFF BEARING

36631

GASKET, POWER TAKE-OFF BEARING RETAINER

36633

GASKET, POWER TAKE-OFF

36714

GEAR, POWER TAKE-OFF OUTPUT

36718

GEAR, POWER TAKE-OFF IDLER

36718A

BEARING(FOR POWER TAKE-OFF IDLER GEAR FRONT)

36718B

BEARING(FOR POWER TAKE-OFF IDLER GEAR REAR)

36718C

RING, HOLE SNAP(FOR POWER TAKE-OFF IDLER GEAR)

36718D

SPACER(FOR POWER TAKE-OFF IDLER GEAR)

36723

SHAFT, POWER TAKE-OFF OUTPUT, NO.1

36723A

BEARING (FOR OUTPUT SHAFT FRONT)

36723B

BEARING (FOR OUTPUT SHAFT REAR)

36723C

KEY, WOODRUFF (FOR POWER TAKE-OFF OUTPUT SHAFT)

36728

SHAFT, POWER TAKE-OFF IDLER

36728A

RING, O (FOR POWER TAKE-OFF IDLER SHAFT)

36811

FORK, POWR TAKE-OFF SHIFT, NO.1

36814

SHAFT, POWR TAKE-OFF FORK, NO.1

36851

RETAINER, POWER TAKE-OFF JOINT

9111140814

Крепеж

9111140820

Крепеж

9161161025

Крепеж

9411051000

Крепеж

9414541200

Крепеж

9451200800

Крепеж

9451201000

Крепеж

9461211200

Крепеж

9538103028

Крепеж

Код

Описание

36610

POWER TAKE-OFF ASSY

36610A

BOLT, LOCK BALL (FOR POWER TAKE-OFF)

36610B

GASKET, SEAT (FOR POWER TAKE-OFF)

36610C

SPRING, GEAR SHIFT FORK LOCK BALL (FOR POWER TAKE-OFF)

36610D

BALL, GEAR SHIFT FORK LOCK (FOR POWER TAKE-OFF)

36610E

SEAL, OIL (FOR POWER TAKE-OFF)

36610J

PLATE OR PIN, LOCK (FOR POWER TAKE-OFF)

36611

CASE, POWER TAKE-OFF

36611A

BOLT, STUD (FOR POWER TAKE-OFF CASE)

36611C

PLUG, W/HEAD STRAIGHT SCREW (FOR POWER TAKE-OFF CACE)

36621

RETAINER, POWER TAKE-OFF BEARING

36621A

SEAL, OIL (FOR POWER TAKE-OFF BEARING RETAINER)

36622

CAP, POWER TAKE-0FF BEARING

36631

GASKET, POWER TAKE-OFF BEARING RETAINER

36633

GASKET, POWER TAKE-OFF

36714

GEAR, POWER TAKE-OFF OUTPUT

36718

GEAR, POWER TAKE-OFF IDLER

36718A

BEARING(FOR POWER TAKE-OFF IDLER GEAR FRONT)

36718B

BEARING(FOR POWER TAKE-OFF IDLER GEAR REAR)

36718C

RING, HOLE SNAP(FOR POWER TAKE-OFF IDLER GEAR)

36718D

SPACER(FOR POWER TAKE-OFF IDLER GEAR)

36723

SHAFT, POWER TAKE-OFF OUTPUT, NO.1

36723A

BEARING (FOR OUTPUT SHAFT FRONT)

36723B

BEARING (FOR OUTPUT SHAFT REAR)

36723C

KEY, WOODRUFF (FOR POWER TAKE-OFF OUTPUT SHAFT)

36723E

SPACER (FOR POWER TAKE-OFF OUTPUT SHAFT BEARING)

36728

SHAFT, POWER TAKE-OFF IDLER

36728A

RING, O (FOR POWER TAKE-OFF IDLER SHAFT)

36811

FORK, POWR TAKE-OFF SHIFT, NO.1

36814

SHAFT, POWR TAKE-OFF FORK, NO.1

36814E

RING, E (FOR POWER TAKE-OFF SHIFT SHAFT)

36814P

PIN (FOR POWER TAKE-OFF SHIFT SHAFT)

36851

RETAINER, POWER TAKE-OFF JOINT

9010110052

Крепеж

9020114002

Крепеж

9021414001

Крепеж

9111140816

Крепеж

9111140820

Крепеж

9411051000

Крепеж

9412541400

Крепеж

9451100800

Крепеж

9451201000

Крепеж

Код

Описание

36610

POWER TAKE-OFF ASSY

36610A

BOLT, LOCK BALL (FOR POWER TAKE-OFF)

36610B

GASKET, SEAT (FOR POWER TAKE-OFF)

36610C

SPRING, GEAR SHIFT FORK LOCK BALL (FOR POWER TAKE-OFF)

36610D

BALL, GEAR SHIFT FORK LOCK (FOR POWER TAKE-OFF)

36610E

SEAL, OIL (FOR POWER TAKE-OFF)

36610J

PLATE OR PIN, LOCK (FOR POWER TAKE-OFF)

36611

CASE, POWER TAKE-OFF

36611A

BOLT, STUD (FOR POWER TAKE-OFF CASE)

36621

RETAINER, POWER TAKE-OFF BEARING

36621A

SEAL, OIL (FOR POWER TAKE-OFF BEARING RETAINER)

36631

GASKET, POWER TAKE-OFF BEARING RETAINER

36633

GASKET, POWER TAKE-OFF

36652

SPACER, POWER TAKE-OFF CASE

36714

GEAR, POWER TAKE-OFF OUTPUT

36718

GEAR, POWER TAKE-OFF IDLER

36718A

BEARING(FOR POWER TAKE-OFF IDLER GEAR FRONT)

36718B

BEARING(FOR POWER TAKE-OFF IDLER GEAR REAR)

36718C

RING, HOLE SNAP(FOR POWER TAKE-OFF IDLER GEAR)

36718D

SPACER(FOR POWER TAKE-OFF IDLER GEAR)

36718E

SPACER(POWER TAKE-OFF BEARING RETAINER)

36723

SHAFT, POWER TAKE-OFF OUTPUT, NO.1

36723A

BEARING (FOR OUTPUT SHAFT FRONT)

36723B

BEARING (FOR OUTPUT SHAFT REAR)

36723C

KEY, WOODRUFF (FOR POWER TAKE-OFF OUTPUT SHAFT)

36723E

SPACER (FOR POWER TAKE-OFF OUTPUT SHAFT BEARING)

36728

SHAFT, POWER TAKE-OFF IDLER

36811

FORK, POWR TAKE-OFF SHIFT, NO.1

36814

SHAFT, POWR TAKE-OFF FORK, NO.1

36814E

RING, E (FOR POWER TAKE-OFF SHIFT SHAFT)

36814P

PIN (FOR POWER TAKE-OFF SHIFT SHAFT)

36817

COVER, POWER TAKE-OFF SHAFT

36851

RETAINER, POWER TAKE-OFF JOINT

9020114002

Крепеж

9021414001

Крепеж

9111140820

Крепеж

9111141035

Крепеж

9411051000

Крепеж

9412541400

Крепеж

9451100800

Крепеж

9451201000

Крепеж

Код

Описание

36610

POWER TAKE-OFF ASSY

36610A

BOLT, LOCK BALL (FOR POWER TAKE-OFF)

36610B

GASKET, SEAT (FOR POWER TAKE-OFF)

36610C

SPRING, GEAR SHIFT FORK LOCK BALL (FOR POWER TAKE-OFF)

36610D

BALL, GEAR SHIFT FORK LOCK (FOR POWER TAKE-OFF)

36610E

SEAL, OIL (FOR POWER TAKE-OFF)

36610F

PLUG, EXPANSION (FOR POWER TAKE-OFF)

36611

CASE, POWER TAKE-OFF

36611A

BOLT, STUD (FOR POWER TAKE-OFF CASE)

36621

RETAINER, POWER TAKE-OFF BEARING

36621A

SEAL, OIL (FOR POWER TAKE-OFF BEARING RETAINER)

36624

CAP, POWER TAKE-OFF BEARING

36631

GASKET, POWER TAKE-OFF BEARING RETAINER

36632

GASKET, POWER TAKE-OFF JOINT RETAINER

36633

GASKET, POWER TAKE-OFF

36652

SPACER, POWER TAKE-OFF CASE

36714

GEAR, POWER TAKE-OFF OUTPUT

36718

GEAR, POWER TAKE-OFF IDLER

36718A

BEARING(FOR POWER TAKE-OFF IDLER GEAR FRONT)

36718B

BEARING(FOR POWER TAKE-OFF IDLER GEAR REAR)

36718C

RING, HOLE SNAP(FOR POWER TAKE-OFF IDLER GEAR)

36718D

SPACER(FOR POWER TAKE-OFF IDLER GEAR)

36723

SHAFT, POWER TAKE-OFF OUTPUT, NO.1

36723A

BEARING (FOR OUTPUT SHAFT FRONT)

36723B

BEARING (FOR OUTPUT SHAFT REAR)

36723C

KEY, WOODRUFF (FOR POWER TAKE-OFF OUTPUT SHAFT)

36728

SHAFT, POWER TAKE-OFF IDLER

36728A

RING, O (FOR POWER TAKE-OFF IDLER SHAFT)

36733

SPACER, JOINT RETAINER

36811

FORK, POWR TAKE-OFF SHIFT, NO.1

36814

SHAFT, POWR TAKE-OFF FORK, NO.1

36814C

SPACER (FOR POWER TAKE-OFF FORK SHAFT)

36851

RETAINER, POWER TAKE-OFF JOINT

38541

LEVER, SHIFT

38542

PIN, SHIFT LEVER

3896496301

Крепеж

9111140814

Крепеж

9111140820

Крепеж

9111150825

Крепеж

9161161050

Крепеж

9411041000

Крепеж

9411051000

Крепеж

9412040800

Крепеж

9414541200

Крепеж

9451100800

Крепеж

9451200800

Крепеж

9451201000

Крепеж

9461211200

Крепеж

9461310800

Крепеж

9538103028

Крепеж

9645100600

Крепеж

POWER TAKE-OFF CASE & GEAR TOYOTA DYNA, 1983/02 - 1984/08, 3 литра, дизель, TRUCK (EXCLUDING DUMP TRUCK), BU22, МКПП, 5 скоростей, на руле
