Задние кресла TOYOTA WISH, 2003/01 - 2005/08, 1,8 литра, 16 клапанов DOHC, EFI, X TYPE, ZNE14

Каталог

Япония

Модель

WISH

Двигатель

1,8 литра, 16 клапанов DOHC, EFI

Класс

X TYPE

Фрейм

ZNE14

Опции

7-местный 251W

Код

Описание

6701

переход к группе запчастей

71037

HINGE SUB-ASSY, CENTER SEAT BACK, RH

7104

переход к группе запчастей

71075E

CLIP(FOR REAR SEAT)

71393A

BAND, REAR SEAT CUSHION, RH

71461

SPRING, REAR SEAT CUSHION

71811G

SHIELD, REAR SEAT CUSHION, RH

71861A

SHIELD, REAR SEAT CUSHION, INNER RH

71875C

COVER, RECLINING ADJUSTER INSIDE, RH

71876B

COVER, RECLINING ADJUSTER INSIDE, LH

71931A

SUPPORT, REAR SEAT HEADREST

71940A

HEADREST ASSY, REAR SEAT

71960B

HEADREST ASSY, REAR SEAT, CENTER

72057

LEVER SUB-ASSY, REAR SEAT LOCK CONTROL, RH

72124C

COVER, SEAT TRACK BRACKET, OUTER FRONT LH

72137D

COVER, REAR SEAT TRACK, RH

72160

TRACK ASSY, REAR SEAT, OUTER RH

72170

TRACK ASSY, REAR SEAT, OUTER LH

72173

HANDLE, REAR SEAT TRACK ADJUSTING

7218968010

Крепеж

72507B

HANDLE SUB-ASSY, RECLINING RELEASE, RH

72525C

HANDLE, RECLINING ADJUSTER RELEASE, NO.1 RH

72595

BASE, RECLINING REMOTE CONTROL, RH

72704A

CABLE, REAR SEAT RECLINING CONTROL

72830

ARMREST ASSY, REAR SEAT, CENTER

72833A

PLATE, SEAT CENTER ARMREST, INNER

72927

COVER, REAR SEAT CUSHION UNDER, RH

73115A

CLIP, BELT COMFORT, NO.1

78955

COVER, REAR SEAT UNDER TRAY RH

79011

COVER SUB-ASSY, NO.1 SEAT CUSHION, RH

79013

COVER SUB-ASSY, NO.1 SEAT BACK, RH

79101

FRAME SUB-ASSY, NO.1 SEAT CUSHION

79105

LEG SUB-ASSY, NO.1 SEAT, RH

79109

BOARD SUB-ASSY, NO.1 SEAT BACK

79109A

CLIP (FOR NO.1 SEAT BACK BOARD)

79135A

PAD, NO.1 SEAT CUSHION, RH

79139J

CLOTH, NO.1 SEAT CUSHION RH

79175E

PAD, NO.1 SEAT BACK, RH

79180A

SPRING ASSY, NO.1 SEAT BACK, RH

9010506216

Крепеж

9011910327

Крепеж

9011910886

Крепеж

9016845002

Крепеж

9017908025

Крепеж

9151581025

Крепеж

9165140620

Крепеж

9321056008

Крепеж

9356854512

Крепеж

9415081000

Крепеж

Код

Описание

6701

переход к группе запчастей

7104

переход к группе запчастей

71075E

CLIP(FOR REAR SEAT)

71393B

BAND, REAR SEAT CUSHION, LH

71462

SPRING, REAR SEAT CUSHION, NO.2

71812E

COVER, RECLINING ADJUSTER, LH

71862A

SHIELD, REAR SEAT CUSHION, INNER LH

71875E

COVER, RECLINING ADJUSTER INSIDE, RH

71876E

COVER, RECLINING ADJUSTER INSIDE, LH

71931A

SUPPORT, REAR SEAT HEADREST

71940A

HEADREST ASSY, REAR SEAT

72058A

LEVER SUB-ASSY, REAR SEAT LOCK CONTROL, LH

72124C

COVER, SEAT TRACK BRACKET, OUTER FRONT LH

72138A

COVER, REAR SEAT TRACK, LH

72160

TRACK ASSY, REAR SEAT, OUTER RH

72170D

TRACK ASSY, REAR SEAT, OUTER LH

72173

HANDLE, REAR SEAT TRACK ADJUSTING

7218968010

Крепеж

72507C

HANDLE SUB-ASSY, RECLINING RELEASE, LH

72526B

HANDLE, RECLINING ADJUSTER RELEASE, NO.1 LH

72595

BASE, RECLINING REMOTE CONTROL, RH

72704B

CABLE, REAR SEAT RECLINING CONTROL, NO.2

72928

COVER, REAR SEAT CUSHION UNDER, LH

73115A

CLIP, BELT COMFORT, NO.1

73387

BAND, RR SEAT BELT GUIDE, NO.1

78955

COVER, REAR SEAT UNDER TRAY RH

79012

COVER SUB-ASSY, NO.1 SEAT CUSHION, LH

79014

COVER SUB-ASSY, NO.1 SEAT BACK, LH

79106

LEG SUB ASSY, NO.1 SEAT, LH

79136B

PAD, NO.1 SEAT CUSHION, LH

79139K

CLOTH, NO.1 SEAT CUSHION LH

79185

PAD, NO.1 SEAT BACK, LH

79190A

SPRING ASSY, NO.1 SEAT BACK, LH

79201

FRAME SUB-ASSY, NO.2 SEAT CUSHION

79209

BOARD SUB-ASSY, NO.2 SEAT BACK

79209A

CLIP (FOR NO.2 SEAT BACK BOARD)

9010506216

Крепеж

9011910886

Крепеж

9016845002

Крепеж

9017908025

Крепеж

9151581025

Крепеж

9321056008

Крепеж

9356854512

Крепеж

9415081000

Крепеж

Код

Описание

71037

HINGE SUB-ASSY, CENTER SEAT BACK, RH

7104

переход к группе запчастей

71075E

CLIP(FOR REAR SEAT)

71393A

BAND, REAR SEAT CUSHION, RH

71461

SPRING, REAR SEAT CUSHION

71811G

SHIELD, REAR SEAT CUSHION, RH

71861A

SHIELD, REAR SEAT CUSHION, INNER RH

71875C

COVER, RECLINING ADJUSTER INSIDE, RH

71876B

COVER, RECLINING ADJUSTER INSIDE, LH

71931A

SUPPORT, REAR SEAT HEADREST

71940A

HEADREST ASSY, REAR SEAT

71960B

HEADREST ASSY, REAR SEAT, CENTER

72057

LEVER SUB-ASSY, REAR SEAT LOCK CONTROL, RH

72124C

COVER, SEAT TRACK BRACKET, OUTER FRONT LH

72137D

COVER, REAR SEAT TRACK, RH

72160

TRACK ASSY, REAR SEAT, OUTER RH

72170

TRACK ASSY, REAR SEAT, OUTER LH

72173

HANDLE, REAR SEAT TRACK ADJUSTING

7218968010

Крепеж

72507B

HANDLE SUB-ASSY, RECLINING RELEASE, RH

72525C

HANDLE, RECLINING ADJUSTER RELEASE, NO.1 RH

72595

BASE, RECLINING REMOTE CONTROL, RH

72601

STRIKER SUB-ASSY, REAR SEAT LOCK

72704A

CABLE, REAR SEAT RECLINING CONTROL

72830

ARMREST ASSY, REAR SEAT, CENTER

72833A

PLATE, SEAT CENTER ARMREST, INNER

72927

COVER, REAR SEAT CUSHION UNDER, RH

73115A

CLIP, BELT COMFORT, NO.1

78955

COVER, REAR SEAT UNDER TRAY RH

79011

COVER SUB-ASSY, NO.1 SEAT CUSHION, RH

79013

COVER SUB-ASSY, NO.1 SEAT BACK, RH

79101

FRAME SUB-ASSY, NO.1 SEAT CUSHION

79105

LEG SUB-ASSY, NO.1 SEAT, RH

79109

BOARD SUB-ASSY, NO.1 SEAT BACK

79109A

CLIP (FOR NO.1 SEAT BACK BOARD)

79135A

PAD, NO.1 SEAT CUSHION, RH

79139J

CLOTH, NO.1 SEAT CUSHION RH

79175E

PAD, NO.1 SEAT BACK, RH

79180A

SPRING ASSY, NO.1 SEAT BACK, RH

9010506216

Крепеж

9011910327

Крепеж

9011910886

Крепеж

9014880038

Крепеж

9017908025

Крепеж

9046707132

Крепеж

9151581025

Крепеж

9165140620

Крепеж

9321056008

Крепеж

9356854512

Крепеж

9415081000

Крепеж

9461211001

Крепеж

Код

Описание

7104

переход к группе запчастей

71075E

CLIP(FOR REAR SEAT)

71393B

BAND, REAR SEAT CUSHION, LH

71462

SPRING, REAR SEAT CUSHION, NO.2

71812E

COVER, RECLINING ADJUSTER, LH

71862A

SHIELD, REAR SEAT CUSHION, INNER LH

71875E

COVER, RECLINING ADJUSTER INSIDE, RH

71876E

COVER, RECLINING ADJUSTER INSIDE, LH

71931A

SUPPORT, REAR SEAT HEADREST

71940A

HEADREST ASSY, REAR SEAT

72058A

LEVER SUB-ASSY, REAR SEAT LOCK CONTROL, LH

72124C

COVER, SEAT TRACK BRACKET, OUTER FRONT LH

72138A

COVER, REAR SEAT TRACK, LH

72160

TRACK ASSY, REAR SEAT, OUTER RH

72170D

TRACK ASSY, REAR SEAT, OUTER LH

72173

HANDLE, REAR SEAT TRACK ADJUSTING

7218968010

Крепеж

72507C

HANDLE SUB-ASSY, RECLINING RELEASE, LH

72526B

HANDLE, RECLINING ADJUSTER RELEASE, NO.1 LH

72595

BASE, RECLINING REMOTE CONTROL, RH

72704B

CABLE, REAR SEAT RECLINING CONTROL, NO.2

72928

COVER, REAR SEAT CUSHION UNDER, LH

73115A

CLIP, BELT COMFORT, NO.1

73387

BAND, RR SEAT BELT GUIDE, NO.1

78955

COVER, REAR SEAT UNDER TRAY RH

79012

COVER SUB-ASSY, NO.1 SEAT CUSHION, LH

79014

COVER SUB-ASSY, NO.1 SEAT BACK, LH

79106

LEG SUB ASSY, NO.1 SEAT, LH

79136B

PAD, NO.1 SEAT CUSHION, LH

79139K

CLOTH, NO.1 SEAT CUSHION LH

79185

PAD, NO.1 SEAT BACK, LH

79190A

SPRING ASSY, NO.1 SEAT BACK, LH

79201

FRAME SUB-ASSY, NO.2 SEAT CUSHION

79209

BOARD SUB-ASSY, NO.2 SEAT BACK

79209A

CLIP (FOR NO.2 SEAT BACK BOARD)

9010506216

Крепеж

9011910886

Крепеж

9017908025

Крепеж

9046707132

Крепеж

9151581025

Крепеж

9321056008

Крепеж

9356854512

Крепеж

9415081000

Крепеж

9461211001

Крепеж

Код

Описание

6701

переход к группе запчастей

6777112080

Крепеж

7104

переход к группе запчастей

71354A

PLATE, REAR SEAT BACK SET

71480A

CLIP (FOR REAR SEAT BACK)

71628E

SPACER, REAR SEAT CUSHION

71701B

BOARD SUB-ASSY, REAR SEAT BACK, RH

71769A

CLIP, REAR SEAT BACK BOARD

71843A

COVER, REAR SEAT RECLINING, NO.2 RH

71844A

COVER, REAR SEAT RECLINING, NO.2 LH

71931E

SUPPORT ASSY, REAR NO.3 SEAT HEADREST

71970

HEADREST ASSY, REAR SEAT

72067

LEVER SUB-ASSY, REAR BACK LOCK CONTROL, RH

72525E

HANDLE, RECLINING ADJUSTER RELEASE, NO.3 RH

72526D

HANDLE, RECLINING ADJUSTER RELEASE, NO.3 LH

72553A

PROTECTOR, RECLINING COVER, RH

72554A

PROTECTOR, RECLINING COVER, LH

7270268040

Крепеж

72704C

CABLE, REAR NO.2 SEAT RECLINING CONTROL

79031B

COVER SUB-ASSY, NO.3 SEAT CUSHION, RH

79033

COVER SUB-ASSY, NO.3 SEAT BACK, RH

79303A

FRAME SUB-ASSY, NO.3 SEAT BACK, RH

79305A

LEG SUB-ASSY, NO.3 SEAT, RH

79319

BRACKET, NO.3 SEAT LEG, RR RH

79335A

PAD, NO.3 SEAT CUSHION, RH

79360A

SPRING ASSY, NO.3 SEAT CUSHION, RH

79372

COVER, NO.3 SEAT FRONT BRACKET, RH

79375A

PAD, NO.3 SEAT BACK, RH

9008416010

Крепеж

9010906292

Крепеж

9010910164

Крепеж

9011910886

Крепеж

9014940012

Крепеж

9016840046

Крепеж

9017906007

Крепеж

9020510008

Крепеж

9155281018

Крепеж

91611G0612

Крепеж

Код

Описание

6701

переход к группе запчастей

6777112080

Крепеж

7104

переход к группе запчастей

71354A

PLATE, REAR SEAT BACK SET

71480A

CLIP (FOR REAR SEAT BACK)

71628E

SPACER, REAR SEAT CUSHION

71702B

BOARD SUB-ASSY, REAR SEAT BACK, LH

71769A

CLIP, REAR SEAT BACK BOARD

71843D

COVER, REAR SEAT RECLINING, NO.2 RH

71844C

COVER, REAR SEAT RECLINING, NO.2 LH

71931E

SUPPORT ASSY, REAR NO.3 SEAT HEADREST

71970

HEADREST ASSY, REAR SEAT

72068

LEVER SUB-ASSY, REAR BACK LOCK CONTROL, LH

72525E

HANDLE, RECLINING ADJUSTER RELEASE, NO.3 RH

72526D

HANDLE, RECLINING ADJUSTER RELEASE, NO.3 LH

72553C

PROTECTOR, RECLINING COVER, RH

72554B

PROTECTOR, RECLINING COVER, LH

7270268040

Крепеж

72704D

CABLE, REAR NO.2 SEAT RECLINING CONTROL

79032

COVER SUB-ASSY, NO.3 SEAT CUSHION, LH

79034

COVER SUB-ASSY, NO.3 SEAT BACK, LH

79304A

FRAME SUB-ASSY, NO.3 SEAT BACK, LH

79306

LEG SUB ASSY, NO.3 SEAT, LH

79329

BRACKET, NO.3 SEAT LEG, RR LH

79345A

PAD, NO.3 SEAT CUSHION, LH

79370A

SPRING ASSY, NO.3 SEAT CUSHION, LH

79372

COVER, NO.3 SEAT FRONT BRACKET, RH

79385A

PAD, NO.3 SEAT BACK, LH

9008416010

Крепеж

9010906292

Крепеж

9010910164

Крепеж

9011910886

Крепеж

9014940012

Крепеж

9016840046

Крепеж

9017906007

Крепеж

9020510008

Крепеж

9155281018

Крепеж

91611G0612

Крепеж

Код

Описание

9046816019

Крепеж

9046818008

Крепеж

Задние кресла TOYOTA WISH, 2003/01 - 2005/08, 1,8 литра, 16 клапанов DOHC, EFI, X TYPE, ZNE14
