Топливный бак и горловина TOYOTA LAND CRUISER PRADO, 2004/08 - 2009/08, 3 литра, турбо-дизель, GX SPECIFICATION, KDJ120, механика, МКПП, 6 скоростей

Каталог

Европа

Модель

LAND CRUISER PRADO

Двигатель

3 литра, турбо-дизель

Класс

GX SPECIFICATION

Фрейм

KDJ120

Трансмиссия

механика МКПП, 6 скоростей

Опции

левый руль 5 дверей 244W

Код

Описание

77012

TUBE SUB-ASSY, FUEL TANK BREATHER

77017B

TUBE SUB-ASSY, FUEL TANK VENT

77035

CABLE SUB-ASSY, FUEL LID LOCK CONTROL

77100

TANK ASSY, FUEL

77144

RETAINER, FUEL PUMP GAUGE

77169A

GASKET, FUEL SUCTION TUBE SET

77201

PIPE SUB-ASSY, FUEL TANK INLET

77204A

TUBE, FUEL TANK RETURN

77209D

TUBE SUB-ASSY, FUEL TANK MAIN

77213B

HOSE, FUEL TANK TO FILLER PIPE

77241L

TUBE, FUEL TANK SUCTION

77241W

CLIP, TUBE JOINT

77253C

HOSE, FUEL, NO.2(FOR FUEL MAIN NO.3 TUBE)

77276

PROTECTOR, FUEL HOSE

77277R

PROTECTOR, FUEL TANK FILLER PIPE

77286P

CLAMP, FUEL TUBE, NO.8

77290

SHIELD ASSY, FUEL TANK FILLER PIPE

77295C

GROMMET, FUEL TUBE

77306

LEVER SUB-ASSY, FUEL LID LOCK OPEN

77310A

CAP ASSY, FUEL TANK

77316

GASKET, FUEL TANK CAP

77350

LID ASSY, FUEL FILLER OPENING

77366

SPRING, FUEL FILLER OPENING LID HINGE

77371L

RING, FUEL TANK FILLER PIPE SHIELD

77377

RETAINER, FUEL FILLER OPENING LID LOCK

77391A

RING, FUEL INLET BOX

77601A

BAND SUB-ASSY, FUEL TANK, NO.1

77602B

BAND SUB-ASSY, FUEL TANK, NO.1 LH

77606

PROTECTOR SUB-ASSY, FUEL TANK, NO.1

77611A

PIN (FOR FUEL TANK BAND)

77643A

PROTECTOR, FUEL TANK, NO.3

77644

BOLT, FUEL TANK

77651B

CUSHION, FUEL TANK

77652A

CUSHION, FUEL TANK, NO.2

77653A

CUSHION, FUEL TANK, NO.3

77681A

SEAT, FUEL TANK BAND

77682

SEAT, FUEL TANK BAND, LH

8401

переход к группе запчастей

9011906361

Крепеж

9011908A33

Крепеж

9017908234

Крепеж

9018906212

Крепеж

9026906017

Крепеж

9046022002

Крепеж

9046046004

Крепеж

9046055003

Крепеж

9046400042

Крепеж

9046814032

Крепеж

9046906005

Крепеж

9095904001

Крепеж

91651B0820

Крепеж

9613241500

Крепеж

Код

Описание

77012

TUBE SUB-ASSY, FUEL TANK BREATHER

77017B

TUBE SUB-ASSY, FUEL TANK VENT

77035

CABLE SUB-ASSY, FUEL LID LOCK CONTROL

77100

TANK ASSY, FUEL

77144

RETAINER, FUEL PUMP GAUGE

77169A

GASKET, FUEL SUCTION TUBE SET

77201

PIPE SUB-ASSY, FUEL TANK INLET

77204A

TUBE, FUEL TANK RETURN

77209D

TUBE SUB-ASSY, FUEL TANK MAIN

77213B

HOSE, FUEL TANK TO FILLER PIPE

77241L

TUBE, FUEL TANK SUCTION

77241W

CLIP, TUBE JOINT

77253C

HOSE, FUEL, NO.2(FOR FUEL MAIN NO.3 TUBE)

77259C

HOSE, FUEL

77276

PROTECTOR, FUEL HOSE

77277R

PROTECTOR, FUEL TANK FILLER PIPE

77285C

CLAMP, FUEL TUBE, NO.1 (FOR FRONT FUEL MAIN)

77286P

CLAMP, FUEL TUBE, NO.8

77290

SHIELD ASSY, FUEL TANK FILLER PIPE

77295C

GROMMET, FUEL TUBE

77306

LEVER SUB-ASSY, FUEL LID LOCK OPEN

77310A

CAP ASSY, FUEL TANK

77316

GASKET, FUEL TANK CAP

77350

LID ASSY, FUEL FILLER OPENING

77366

SPRING, FUEL FILLER OPENING LID HINGE

77371L

RING, FUEL TANK FILLER PIPE SHIELD

77377

RETAINER, FUEL FILLER OPENING LID LOCK

77391A

RING, FUEL INLET BOX

77601A

BAND SUB-ASSY, FUEL TANK, NO.1

77602B

BAND SUB-ASSY, FUEL TANK, NO.1 LH

77606

PROTECTOR SUB-ASSY, FUEL TANK, NO.1

77611A

PIN (FOR FUEL TANK BAND)

77643A

PROTECTOR, FUEL TANK, NO.3

77644

BOLT, FUEL TANK

77651B

CUSHION, FUEL TANK

77652A

CUSHION, FUEL TANK, NO.2

77653A

CUSHION, FUEL TANK, NO.3

77681A

SEAT, FUEL TANK BAND

77682

SEAT, FUEL TANK BAND, LH

8401

переход к группе запчастей

9011906361

Крепеж

9011908A33

Крепеж

9017908234

Крепеж

9018906212

Крепеж

9026906017

Крепеж

9046022002

Крепеж

9046046004

Крепеж

9046055003

Крепеж

9046400042

Крепеж

9046814032

Крепеж

9046906005

Крепеж

9095904001

Крепеж

91651B0820

Крепеж

9613241500

Крепеж

9613251300

Крепеж

Код

Описание

2202

переход к группе запчастей

2302

переход к группе запчастей

77251B

TUBE, FUEL MAIN

77251C

HOSE, FUEL, NO.1(FOR FUEL MAIN TUBE)

77255D

TUBE, FUEL RETURN

77255F

HOSE, FUEL, NO.2 (FOR FUEL RETURN TUBE)

77256C

TUBE, FUEL RETURN, NO.2

77257C

TUBE, FUEL RETURN, NO.3

77257D

HOSE, FUEL, NO.1(FOR FUEL RETURN NO.3 TUBE)

77257E

HOSE, FUEL, NO.2(FOR FUEL RETURN NO.3 TUBE)

77285B

CLAMP, FUEL TUBE W/GROMMET, NO.1

77285C

CLAMP, FUEL TUBE, NO.1 (FOR FRONT FUEL MAIN)

77285D

CLAMP, FUEL TUBE, NO.1

77285E

CLAMP, FUEL TUBE W/GROMMET, NO.1

77285F

CLAMP, FUEL TUBE, NO.1

77285G

CLAMP, FUEL TUBE, NO.1

77285H

CLAMP, FUEL TUBE, NO.1

77285J

CLAMP, FUEL TUBE, NO.1

77285K

CLAMP, FUEL TUBE, NO.1

77285L

CLAMP, FUEL TUBE, NO.1

77285M

CLAMP, FUEL TUBE, NO.1

77295E

GROMMET, FUEL TUBE

9017906161

Крепеж

9046400726

Крепеж

9613251300

Крепеж

9613541400

Крепеж

Код

Описание

2202

переход к группе запчастей

2302

переход к группе запчастей

23917

COOLER, FUEL

77251B

TUBE, FUEL MAIN

77251C

HOSE, FUEL, NO.1(FOR FUEL MAIN TUBE)

77251D

HOSE, FUEL, NO.2(FOR FUEL MAIN TUBE)

77255C

HOSE, FUEL, NO.3 (FOR EMISSION TUBE, NO.2)

77255D

TUBE, FUEL RETURN

77256C

TUBE, FUEL RETURN, NO.2

77266A

PROTECTOR, FUEL TUBE, NO.1

77277A

HOSE, FUEL, NO.1(FOR RETURN TUBE, NO.1)

77278B

HOSE, FUEL, NO.2 (FOR RETURN TUBE, NO.2)

77285B

CLAMP, FUEL TUBE W/GROMMET, NO.1

77285D

CLAMP, FUEL TUBE, NO.1

77285E

CLAMP, FUEL TUBE W/GROMMET, NO.1

77285F

CLAMP, FUEL TUBE, NO.1

77285G

CLAMP, FUEL TUBE, NO.1

77285H

CLAMP, FUEL TUBE, NO.1

77285J

CLAMP, FUEL TUBE, NO.1

77285K

CLAMP, FUEL TUBE, NO.1

77286H

CLAMP, FUEL TUBE, NO.3

9017806012

Крепеж

9017906161

Крепеж

9613241500

Крепеж

9613251300

Крепеж

9613541400

Крепеж

Топливный бак и горловина TOYOTA LAND CRUISER PRADO, 2004/08 - 2009/08, 3 литра, турбо-дизель, GX SPECIFICATION, KDJ120, механика, МКПП, 6 скоростей
