Распредвал, клапаны, ремень TOYOTA HIACE TRUCK, 1987/10 - 1995/05, 2,4 литра, дизель, LH85, механика, МКПП, 5 скоростей

Каталог

Япония

Модель

HIACE TRUCK

Двигатель

2,4 литра, дизель

Фрейм

LH85

Трансмиссия

механика МКПП, 5 скоростей

Опции

BOARDING DECK HIGH FLAT DECK OPENING ON THREE SIDES SINGAPORE TAXI COMPLETED VEHICLE

Код

Описание

11802

BEARING SET, CAMSHAFT

13502

IDLER SUB-ASSY, TIMING BELT, NO.2

13505

IDLER SUB-ASSY, TIMING BELT, NO.1

13505A

SPRING, TENSION(FOR IDLER)

13511

CAMSHAFT

13511A

PIN, STRAIGHT(FOR CAMSHAFT KNOCK)

13523P

PULLEY, CAMSHAFT TIMING

13558

BRACKET, SPRING(FOR IDLER)

13568

BELT, TIMING

13613P

PULLEY, INJECTION PUMP DRIVE

13711

VALVE, INTAKE

13711A

SEAL OR RING, O(FOR VALVE STEM OIL)

13711B

SPRING, COMPRESSION(FOR INNER)

13711D

WASHER, PLATE(FOR VALVE SPRING SEAT)

13715

VALVE, EXHAUST

13741

RETAINER, VALVE SPRING

13741A

LOCK, VALVE SPRING RETAINER

13801

ARM SUB-ASSY, VALVE ROCKER, NO.1

13801B

NUT, HEXAGON(FOR VALVE ADJUSTING)

13801C

SCREW, VALVE ADJUSTING

13801D

SPRING, COMPRESSION(FOR ROCKER ARM)

13802

ARM SUB-ASSY, VALVE ROCKER, NO.2

13901

SHAFT SUB-ASSY, VALVE ROCKER, NO.1

13951

SUPPORT, VALVE ROCKER, NO.1

13951A

BOLT(FOR ROCKER SUPPORT SET)

13951B

SCREW OR BOLT(FOR VALVE ROCKER SHAFT LOCK)

1709

переход к группе запчастей

9009905166

Крепеж

9010510061

Крепеж

9010908021

Крепеж

9011914036

Крепеж

9020108001

Крепеж

9020109562

Крепеж

9161160850

Крепеж

Код

Описание

11802

BEARING SET, CAMSHAFT

13502

IDLER SUB-ASSY, TIMING BELT, NO.2

13505

IDLER SUB-ASSY, TIMING BELT, NO.1

13505A

SPRING, TENSION(FOR IDLER)

13511

CAMSHAFT

13511A

PIN, STRAIGHT(FOR CAMSHAFT KNOCK)

13523P

PULLEY, CAMSHAFT TIMING

13558

BRACKET, SPRING(FOR IDLER)

13568

BELT, TIMING

13613P

PULLEY, INJECTION PUMP DRIVE

13711

VALVE, INTAKE

13711A

SEAL OR RING, O(FOR VALVE STEM OIL)

13711B

SPRING, COMPRESSION(FOR INNER)

13711D

WASHER, PLATE(FOR VALVE SPRING SEAT)

13715

VALVE, EXHAUST

13741

RETAINER, VALVE SPRING

13741A

LOCK, VALVE SPRING RETAINER

13801

ARM SUB-ASSY, VALVE ROCKER, NO.1

13801B

NUT, HEXAGON(FOR VALVE ADJUSTING)

13801C

SCREW, VALVE ADJUSTING

13801D

SPRING, COMPRESSION(FOR ROCKER ARM)

13802

ARM SUB-ASSY, VALVE ROCKER, NO.2

13901

SHAFT SUB-ASSY, VALVE ROCKER, NO.1

13951

SUPPORT, VALVE ROCKER, NO.1

13951A

BOLT(FOR ROCKER SUPPORT SET)

13951B

SCREW OR BOLT(FOR VALVE ROCKER SHAFT LOCK)

1709

переход к группе запчастей

9009905166

Крепеж

9010510061

Крепеж

9010908021

Крепеж

9011914036

Крепеж

9020108001

Крепеж

9020109562

Крепеж

9161160850

Крепеж

Код

Описание

11802

BEARING SET, CAMSHAFT

13502

IDLER SUB-ASSY, TIMING BELT, NO.2

13505

IDLER SUB-ASSY, TIMING BELT, NO.1

13505A

SPRING, TENSION(FOR IDLER)

13511

CAMSHAFT

13523A

KEY, WOODRUFF(FOR TIMING GEAR)

13523P

PULLEY, CAMSHAFT TIMING

13558

BRACKET, SPRING(FOR IDLER)

13568

BELT, TIMING

13613P

PULLEY, INJECTION PUMP DRIVE

13711

VALVE, INTAKE

13711A

SEAL OR RING, O(FOR VALVE STEM OIL)

13711B

SPRING, COMPRESSION(FOR INNER)

13711D

WASHER, PLATE(FOR VALVE SPRING SEAT)

13715

VALVE, EXHAUST

13741

RETAINER, VALVE SPRING

13741A

LOCK, VALVE SPRING RETAINER

13751

LIFTER, VALVE

13753

SHIM, VALVE ADJUSTING

1709

переход к группе запчастей

9009905166

Крепеж

9010508169

Крепеж

9010510235

Крепеж

9010908171

Крепеж

9010908172

Крепеж

9011914036

Крепеж

9056012041

Крепеж
