Кресла TOYOTA HIACE/REGIUSACE, 1990/10 - 1993/08, 2,4 литра, дизель, фургон, SWITCH:SIDE WIPER, LH110, МКПП, 5 скоростей

Каталог

Япония

Модель

HIACE/REGIUSACE

Двигатель

2,4 литра, дизель

Кузов

фургон

Класс

SWITCH:SIDE WIPER

Фрейм

LH110

Трансмиссия

МКПП, 5 скоростей

Опции

STANDARD ROOF 4 двери боковое стекло 9-местный DSL 2WD

Код

Описание

71011S

FRAME SUB-ASSY, FRONT SEAT CUSHION, RH

71013S

FRAME SUB-ASSY, FRONT SEAT BACK, RH

71014S

FRAME SUB-ASSY, FRONT SEAT BACK, LH

71035S

COVER, FRONT SEAT BACK, CENTER

71071S

COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71072S

COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

71073S

COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71074S

COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71128

PLATE, FRONT SEAT CUSHION COVER SET, OUTSIDE LH

71274

KNOB, FRONT SEAT HINGE

71350S

BACK ASSY, FRONT SEAT, CENTER

71358

PAD, CENTER SEAT BACK

71380

HINGE ASSY, CENTER SEAT, RH

71392

COVER, CENTER SEAT CUSHION BRACKET, LH

71395B

COVER, CENTER SEAT HINGE, RH

71410S

CUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71420S

CUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE)

71430S

BACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71440S

BACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE)

71511S

PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71512S

PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE)

71551S

PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71552S

PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71811C

COVER, RECLINING ADJUSTER, RH

71831D

COVER, FRONT SEAT HINGE, RH

71832D

COVER, FRONT SEAT HINGE, LH

72110A

TRACK ASSY, FRONT SEAT, OUTER RH

72130A

TRACK ASSY, FRONT SEAT, INNER RH

72213

KNOB, SEAT TRACK ADJUSTING HANDLE

72510

ADJUSTER ASSY, RECLINING SEAT BACK, RH

72525A

HANDLE, RECLINING ADJUSTER RELEASE, RH

72658C

KNOB, FRONT SEAT LOCK HANDLE

73178B

CAP, SEAT BELT ANCHOR COVER

9010508109

Крепеж

9011908079

Крепеж

9011910101

Крепеж

9011910854

Крепеж

9011910855

Крепеж

9016740044

Крепеж

9017910073

Крепеж

9038610027

Крепеж

9038612051

Крепеж

9038612061

Крепеж

9046708008

Крепеж

9052308001

Крепеж

91612B1020

Крепеж

9354054012

Крепеж

Код

Описание

71011S

FRAME SUB-ASSY, FRONT SEAT CUSHION, RH

71013S

FRAME SUB-ASSY, FRONT SEAT BACK, RH

71014S

FRAME SUB-ASSY, FRONT SEAT BACK, LH

71035S

COVER, FRONT SEAT BACK, CENTER

71071S

COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71072S

COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

71073S

COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71074S

COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71128

PLATE, FRONT SEAT CUSHION COVER SET, OUTSIDE LH

71274

KNOB, FRONT SEAT HINGE

71350S

BACK ASSY, FRONT SEAT, CENTER

71358

PAD, CENTER SEAT BACK

71380

HINGE ASSY, CENTER SEAT, RH

71392

COVER, CENTER SEAT CUSHION BRACKET, LH

71395B

COVER, CENTER SEAT HINGE, RH

71410S

CUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71420S

CUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE)

71430S

BACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71440S

BACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE)

71511S

PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71512S

PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE)

71551S

PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71552S

PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71811C

COVER, RECLINING ADJUSTER, RH

71812C

COVER, RECLINING ADJUSTER, LH

71831D

COVER, FRONT SEAT HINGE, RH

71832D

COVER, FRONT SEAT HINGE, LH

71910A

HEADREST ASSY, FRONT SEAT

71931

SUPPORT, FRONT SEAT HEADREST

72110A

TRACK ASSY, FRONT SEAT, OUTER RH

72130A

TRACK ASSY, FRONT SEAT, INNER RH

72213

KNOB, SEAT TRACK ADJUSTING HANDLE

72510

ADJUSTER ASSY, RECLINING SEAT BACK, RH

72525A

HANDLE, RECLINING ADJUSTER RELEASE, RH

72526

HANDLE, RECLINING ADJUSTER RELEASE, LH

72658C

KNOB, FRONT SEAT LOCK HANDLE

73178B

CAP, SEAT BELT ANCHOR COVER

9010508109

Крепеж

9011908079

Крепеж

9011910101

Крепеж

9011910116

Крепеж

9011910855

Крепеж

9016740044

Крепеж

9017910073

Крепеж

9038610027

Крепеж

9038612051

Крепеж

9046708008

Крепеж

9052308001

Крепеж

91612B1020

Крепеж

9354054012

Крепеж

Код

Описание

71011S

FRAME SUB-ASSY, FRONT SEAT CUSHION, RH

71012S

FRAME SUB-ASSY, FRONT SEAT CUSHION, LH

71013S

FRAME SUB-ASSY, FRONT SEAT BACK, RH

71014S

FRAME SUB-ASSY, FRONT SEAT BACK, LH

71071S

COVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71072S

COVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

71073S

COVER, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71074S

COVER, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71128

PLATE, FRONT SEAT CUSHION COVER SET, OUTSIDE LH

71410S

CUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71420S

CUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE)

71430S

BACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

71440S

BACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE)

71511S

PAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

71512S

PAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE)

71537A

PROTECTOR, FRONT SEAT CUSHION

71551S

PAD, FRONT SEAT BACK, RH(FOR SEPARATE TYPE)

71552S

PAD, FRONT SEAT BACK, LH(FOR SEPARATE TYPE)

71705

BOARD SUB-ASSY, FRONT SEAT BACK, RH

71706

BOARD SUB-ASSY, FRONT SEAT BACK, LH

71811C

COVER, RECLINING ADJUSTER, RH

71812C

COVER, RECLINING ADJUSTER, LH

71831D

COVER, FRONT SEAT HINGE, RH

71832D

COVER, FRONT SEAT HINGE, LH

71910A

HEADREST ASSY, FRONT SEAT

71931

SUPPORT, FRONT SEAT HEADREST

72110A

TRACK ASSY, FRONT SEAT, OUTER RH

72120

TRACK ASSY, FRONT SEAT, OUTER LH

72130A

TRACK ASSY, FRONT SEAT, INNER RH

72137

COVER, SEAT TRACK, OUTER RH

72137C

COVER, SEAT TRACK INNER, RH

72140A

TRACK ASSY, FRONT SEAT,INNER LH

72213

KNOB, SEAT TRACK ADJUSTING HANDLE

72296

BEZEL, FRONT SEAT SLIDE SWITCH

72297

BRACKET, FRONT SEAT SLIDE SWITCH

72525A

HANDLE, RECLINING ADJUSTER RELEASE, RH

72526

HANDLE, RECLINING ADJUSTER RELEASE, LH

73178B

CAP, SEAT BELT ANCHOR COVER

8401

переход к группе запчастей

9010508109

Крепеж

9011908079

Крепеж

9011908269

Крепеж

9011910101

Крепеж

9011910116

Крепеж

9016740044

Крепеж

9017910073

Крепеж

9038610027

Крепеж

9038612051

Крепеж

9046708008

Крепеж

9053006007

Крепеж

9161160616

Крепеж

9354054012

Крепеж

Код

Описание

71621A

PAD, REAR SEAT CUSHION SILENCER, A

79011A

COVER SUB-ASSY, NO.1 SEAT CUSHION

79013A

COVER SUB-ASSY, NO.1 SEAT BACK

79120A

CUSHION ASSY, NO.1 SEAT

79135

PAD, NO.1 SEAT CUSHION

79140A

BACK ASSY, NO.1 SEAT

79160

SPRING ASSY, NO.1 SEAT CUSHION

79171A

BRACKET, NO.1 SEAT

79175

PAD, NO.1 SEAT BACK

79180

SPRING ASSY, NO.1 SEAT BACK

9050726009

Крепеж

9161160614

Крепеж

9331516016

Крепеж

Код

Описание

71334A

STOPPER, REAR SEAT LEG

71344A

PLATE, REAR SEAT CUSHION HINGE

71350B

HINGE ASSY, REAR SEAT, RH

71351

KNOB, SEAT HINGE LEVER

71360A

HINGE ASSY, REAR SEAT, LH

71448

STOPPER, REAR SEAT BACK

71485

COVER, REAR SEAT HINGE

71486C

COVER, REAR SEAT HINGE, LH

71499

STOPPER, REAR SEAT BACK

71621A

PAD, REAR SEAT CUSHION SILENCER, A

71691A

COVER, REAR NO.3 SEAT LOCK, RH

71692A

COVER, REAR NO.3 SEAT LOCK, LH

71695

PROTECTOR, REAR SEAT BACK

72050

BELT ASSY, REAR SEAT HOOK

72613A

STRIKER, FRONT SEAT LOCK

72650F

LOCK ASSY, REAR SEAT, RH

72651B

ROD, REAR SEAT LOCK

72658B

KNOB, REAR SEAT LOCK HANDLE

72660F

LOCK ASSY, REAR SEAT, LH

79169

ROD, REAR SEAT HINGE CONNECTOR

79199

HOLDER, NO.1 SEAT LEG STOPPER

9011908364

Крепеж

9011910116

Крепеж

9011910409

Крепеж

9016450020

Крепеж

9016740044

Крепеж

9016840078

Крепеж

9038613016

Крепеж

91612B1020

Крепеж

9161661025

Крепеж

9353044016

Крепеж

9356015020

Крепеж

9616000600

Крепеж

Код

Описание

71499A

STOPPER, REAR SEAT BACK, NO.2

71621A

PAD, REAR SEAT CUSHION SILENCER, A

79021A

COVER SUB-ASSY, NO.2 SEAT CUSHION

79023A

COVER SUB-ASSY, NO.2 SEAT BACK

79175D

PAD, NO.1 SEAT CUSHION, UNDER

79220A

CUSHION ASSY, NO.2 SEAT

79235

PAD, NO.2 SEAT CUSHION

79240A

BACK ASSY, NO.2 SEAT

79260

SPRING ASSY, NO.2 SEAT CUSHION

79275

PAD, NO.2 SEAT BACK

79280

SPRING ASSY, NO.2 SEAT BACK

9011908364

Крепеж

9050726009

Крепеж

9331516016

Крепеж

Код

Описание

71344B

PLATE, REAR SEAT CUSHION HINGE, NO.2

71350D

HINGE ASSY, REAR SEAT, NO.2 RH

71351B

KNOB, SEAT HINGE LEVER, NO.2

71360D

HINGE ASSY, REAR SEAT, NO.2 LH

71485A

COVER, REAR SEAT HINGE, NO.2 RH

71486A

COVER, REAR SEAT HINGE, NO.2 LH

71621B

PAD, REAR SEAT CUSHION SILENCER, NO.2

71691A

COVER, REAR NO.3 SEAT LOCK, RH

71692A

COVER, REAR NO.3 SEAT LOCK, LH

72050A

BELT ASSY, REAR SEAT HOOK

72613A

STRIKER, FRONT SEAT LOCK

72639

KNOB, REAR SEAT LOCK

72650F

LOCK ASSY, REAR SEAT, RH

72651B

ROD, REAR SEAT LOCK

72658D

KNOB, REAR SEAT LOCK HANDLE

72660F

LOCK ASSY, REAR SEAT, LH

79020A

BRACKET ASSY, NO.2 SEAT LEG CONNECTING

79126A

REINFORCEMENT, NO.1 SEAT LEG, NO.1

79126B

REINFORCEMENT, NO.1 SEAT LEG, NO.2

79169

ROD, REAR SEAT HINGE CONNECTOR

79189

STOPPER, NO.1 SEAT LEG

79199

HOLDER, NO.1 SEAT LEG STOPPER

79208A

HOOK SUB-ASSY, NO.2 SEAT LEG

79236C

LINK, NO.2 SEAT LEG

79289

PROTECTOR, NO.2 SEAT BACK

9011908364

Крепеж

9011910116

Крепеж

9011910409

Крепеж

9016450020

Крепеж

9016740044

Крепеж

9016840078

Крепеж

9017608044

Крепеж

9020208056

Крепеж

9020612035

Крепеж

9024908101

Крепеж

9024908204

Крепеж

9024908254

Крепеж

9038613016

Крепеж

9052306017

Крепеж

91612B1020

Крепеж

9161661025

Крепеж

9321056008

Крепеж

9454100800

Крепеж

9616000600

Крепеж

Код

Описание

9046816019

Крепеж

9046818008

Крепеж

Кресла TOYOTA HIACE/REGIUSACE, 1990/10 - 1993/08, 2,4 литра, дизель, фургон, SWITCH:SIDE WIPER, LH110, МКПП, 5 скоростей
