Каталог
Ближний ВостокМодель
COROLLA (S.AMERICA)Двигатель
1,8 литра, 16 клапанов DOHC, EFIКласс
XEI TYPEФрейм
ZZE142Трансмиссия
механикаОпции
левый руль сжатый газ Венесуэла 487W
Код
Описание
23221
PUMP, FUEL
23280J
REGULATOR ASSY, FUEL PRESSURE
23280K
RING, O(FOR FUEL PRESSURE REGULATOR)
77020A
TUBE ASSY, FUEL SUCTION W/PUMP & GAGE
77024A
PLATE SUB-ASSY, FUEL SUCTION
77026A
TUBE SUB-ASSY, FUEL EVAPORATION, NO.1
77035
CABLE SUB-ASSY, FUEL LID LOCK CONTROL
77100
TANK ASSY, FUEL
77144
RETAINER, FUEL PUMP GAUGE
77169A
GASKET, FUEL SUCTION TUBE SET
77174
SUPPORT, FUEL SUCTION, NO.1
77196
CLAMP, EVAPORATION VENT TUBE, NO.1
77197A
CLAMP, EVAPORATION VENT TUBE, NO.2
77201E
PIPE SUB-ASSY, FUEL TANK FILLER
77209D
TUBE SUB-ASSY, FUEL TANK MAIN
77213B
HOSE, FUEL TANK TO FILLER PIPE
77216A
SUPPORT, FUEL TANK FILLER PIPE, NO.1
77217A
SUPPORT, FUEL TANK FILLER PIPE, NO.2
77229E
CLAMP, BREATHER TUBE
77241W
CLIP, TUBE JOINT
77259C
HOSE, FUEL
77276
PROTECTOR, FUEL HOSE
77277R
PROTECTOR, FUEL TANK FILLER PIPE
77279H
RETAINER, FUEL FILLER PIPE PROTECTOR
77281A
CLAMP, FUEL FILLER PIPE
77281G
CLAMP, FUEL HOSE
77286F
CLAMP, FUEL TUBE, NO.2
77286S
CUSHION, FUEL TANK PROTECTOR
77290
SHIELD ASSY, FUEL TANK FILLER PIPE
77295C
GROMMET, FUEL TUBE
77296B
SUPPORT, FUEL TUBE PROTECTOR, NO.1
77306
LEVER SUB-ASSY, FUEL LID LOCK OPEN
77310A
CAP ASSY, FUEL TANK
77316
GASKET, FUEL TANK CAP
77350
LID ASSY, FUEL FILLER OPENING
77358A
STOPPER, FUEL FILLER OPENING LID
77366
SPRING, FUEL FILLER OPENING LID HINGE
77377
RETAINER, FUEL FILLER OPENING LID LOCK
77391
RING, FUEL INLET BOX
77391A
RING, FUEL INLET BOX
77601B
BAND SUB-ASSY, FUEL TANK, NO.1 RH
77602B
BAND SUB-ASSY, FUEL TANK, NO.1 LH
77641A
PROTECTOR, FUEL TANK, NO.1
77651A
CUSHION, FUEL TANK, NO.1
77681
SEAT, FUEL TANK BAND, RH
77682
SEAT, FUEL TANK BAND, LH
77754
HOSE, CHARCOAL CANISTER OUTLET, NO.1
77779
TUBE, CHARCOAL CANISTER OUTLET
77785
HARNESS, FUEL PUMP
8401
переход к группе запчастей
9010508158
Крепеж
9011906391
Крепеж
9011910951
Крепеж
9015960602
Крепеж
9018906232
Крепеж
9026906017
Крепеж
9030108020
Крепеж
9046022002
Крепеж
9046046003
Крепеж
9046046005
Крепеж
9046050008
Крепеж
9046712056
Крепеж
9050609034
Крепеж
91626B0614
Крепеж
9613251300
Крепеж
Код
Описание
23221
PUMP, FUEL
23280J
REGULATOR ASSY, FUEL PRESSURE
23280K
RING, O(FOR FUEL PRESSURE REGULATOR)
77024A
PLATE SUB-ASSY, FUEL SUCTION
77026A
TUBE SUB-ASSY, FUEL EVAPORATION, NO.1
77035
CABLE SUB-ASSY, FUEL LID LOCK CONTROL
77100
TANK ASSY, FUEL
77144
RETAINER, FUEL PUMP GAUGE
77169A
GASKET, FUEL SUCTION TUBE SET
77174
SUPPORT, FUEL SUCTION, NO.1
77196
CLAMP, EVAPORATION VENT TUBE, NO.1
77197A
CLAMP, EVAPORATION VENT TUBE, NO.2
77201E
PIPE SUB-ASSY, FUEL TANK FILLER
77209D
TUBE SUB-ASSY, FUEL TANK MAIN
77213B
HOSE, FUEL TANK TO FILLER PIPE
77216A
SUPPORT, FUEL TANK FILLER PIPE, NO.1
77217A
SUPPORT, FUEL TANK FILLER PIPE, NO.2
77229E
CLAMP, BREATHER TUBE
77241W
CLIP, TUBE JOINT
77276
PROTECTOR, FUEL HOSE
77277R
PROTECTOR, FUEL TANK FILLER PIPE
77279H
RETAINER, FUEL FILLER PIPE PROTECTOR
77281A
CLAMP, FUEL FILLER PIPE
77281G
CLAMP, FUEL HOSE
77286F
CLAMP, FUEL TUBE, NO.2
77286S
CUSHION, FUEL TANK PROTECTOR
77290
SHIELD ASSY, FUEL TANK FILLER PIPE
77292B
SHIELD, FUEL TANK DRAIN PLUG
77293A
SHIELD, FUEL TANK FILLER PIPE, NO.3
77295C
GROMMET, FUEL TUBE
77296B
SUPPORT, FUEL TUBE PROTECTOR, NO.1
77306
LEVER SUB-ASSY, FUEL LID LOCK OPEN
77310A
CAP ASSY, FUEL TANK
77316
GASKET, FUEL TANK CAP
77350
LID ASSY, FUEL FILLER OPENING
77358A
STOPPER, FUEL FILLER OPENING LID
77366
SPRING, FUEL FILLER OPENING LID HINGE
77377
RETAINER, FUEL FILLER OPENING LID LOCK
77391
RING, FUEL INLET BOX
77391A
RING, FUEL INLET BOX
77601B
BAND SUB-ASSY, FUEL TANK, NO.1 RH
77602B
BAND SUB-ASSY, FUEL TANK, NO.1 LH
77641A
PROTECTOR, FUEL TANK, NO.1
77651A
CUSHION, FUEL TANK, NO.1
77681
SEAT, FUEL TANK BAND, RH
77682
SEAT, FUEL TANK BAND, LH
77754
HOSE, CHARCOAL CANISTER OUTLET, NO.1
77779
TUBE, CHARCOAL CANISTER OUTLET
77785
HARNESS, FUEL PUMP
8401
переход к группе запчастей
9010508158
Крепеж
9011906391
Крепеж
9011910951
Крепеж
90119T0006
Крепеж
9015960602
Крепеж
9018906232
Крепеж
9026906017
Крепеж
9030108020
Крепеж
9046022002
Крепеж
9046046003
Крепеж
9046046005
Крепеж
9046050008
Крепеж
9046110781
Крепеж
90466T0040
Крепеж
9046712056
Крепеж
9048026020
Крепеж
9050609034
Крепеж
91621J0612
Крепеж
9613251300
Крепеж
Код
Описание
2384133060
Крепеж
77100
TANK ASSY, FUEL
77161D
PLATE, FUEL TANK PROTECTOR
77167A
SUPPORT, FUEL TANK VENT TUBE, NO.2
77171
GASKET, FUEL TANK TUBE, NO.1
77209E
HOSE SUB-ASSY, FUEL EMISSION
77211
PIPE, FUEL TANK INLET
77243D
JOINT, FUEL TUBE, NO.1
77249
HOSE, FUEL EMISSION
77252A
TUBE, FUEL MAIN, NO.2
77265
CONNECTOR, FUEL MAIN TUBE
77266A
PROTECTOR, FUEL TUBE, NO.1
77278D
VALVE, CHECK W/BRACKET
77279H
RETAINER, FUEL FILLER PIPE PROTECTOR
77281L
CLAMP, FUEL HOSE
77281M
CLAMP, FUEL HOSE
77281N
CLAMP, FUEL HOSE
77285F
CLAMP, FUEL TUBE, NO.1
77286F
CLAMP, FUEL TUBE, NO.2
77295F
GROMMET, FUEL HOSE
77321
COUPLER, FUEL INLET
77322B
WASHER, FUEL INLET COUPLER, NO.1
77323
WASHER, FUEL INLET COUPLER, NO.2
77501T
BRACKET SUB-ASSY, FUEL TANK
77601A
BAND SUB-ASSY, FUEL TANK, NO.1
77617B
COVER, FUEL TANK VALVE, REAR
77644
BOLT, FUEL TANK
77651B
CUSHION, FUEL TANK
77652A
CUSHION, FUEL TANK, NO.2
90119T0006
Крепеж
90119T0065
Крепеж
9015960602
Крепеж
90178T0022
Крепеж
9018906232
Крепеж
9046110781
Крепеж
91626B0614
Крепеж
Код
Описание
1708
переход к группе запчастей
2211
переход к группе запчастей
77251B
TUBE, FUEL MAIN
77261D
TUBE, FUEL TANK TO CANISTER
77285A
SUPPORT, FUEL RETURN AND MAIN TUBE
77285D
CLAMP, FUEL TUBE, NO.1
77298A
CLAMP, FUEL TUBE, NO.4
Код
Описание
1708
переход к группе запчастей
2211
переход к группе запчастей
2603
переход к группе запчастей
4708
переход к группе запчастей
77251B
TUBE, FUEL MAIN
77251J
TUBE, FUEL MAIN, NO.1
77261D
TUBE, FUEL TANK TO CANISTER
77285D
CLAMP, FUEL TUBE, NO.1
77285F
CLAMP, FUEL TUBE, NO.1
77286H
CLAMP, FUEL TUBE, NO.3
77286K
CLAMP, FUEL TUBE, NO.2
77298A
CLAMP, FUEL TUBE, NO.4
77411B
SUPPORT, FUEL TUBE GROMMET, NO.1
9046110651
Крепеж
9046400899
Крепеж
9167180818
Крепеж
