Задние кресла TOYOTA COROLLA SED/WG, 1997/04 - 2000/08, 1,3 литра, 12 клапанов, фургон, XL SPECIFICATION, EE110, механика, МКПП, 5 скоростей

Каталог

Ближний Восток

Модель

COROLLA SED/WG

Двигатель

1,3 литра, 12 клапанов

Кузов

фургон

Класс

XL SPECIFICATION

Фрейм

EE110

Трансмиссия

механика МКПП, 5 скоростей

Опции

левый руль страны Персидского залива

Код

Описание

71075B

COVER, REAR SEAT CUSHION (FOR BENCH TYPE)

71077B

COVER, REAR SEAT BACK (FOR BENCH TYPE)

71281A

HINGE, REAR SEAT CENTER ARMREST

71460B

CUSHION ASSY, REAR SEAT (FOR BENCH TYPE)

71480B

BACK ASSY, REAR SEAT (FOR BENCH TYPE)

71611

PAD, REAR SEAT CUSHION

71651B

PAD, REAR SEAT BACK(FOR BENCH TYPE)

72693

HOOK, REAR SEAT CUSHION LOCK

72830

ARMREST ASSY, REAR SEAT, CENTER

9010906244

Крепеж

9011906242

Крепеж

9011906512

Крепеж

9038608077

Крепеж

9046818071

Крепеж

Код

Описание

71015A

FRAME SUB-ASSY, REAR SEAT CUSHION, RH

71016A

FRAME SUB-ASSY, REAR SEAT CUSHION, LH

71017

FRAME SUB-ASSY, REAR SEAT BACK, RH

71018

FRAME SUB-ASSY, REAR SEAT BACK, LH

71075S

COVER, REAR SEAT CUSHION, RH (FOR SEPARATE TYPE)

71076S

COVER, REAR SEAT CUSHION, LH (FOR SEPARATE TYPE)

71077S

COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE)

71078S

COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE)

71250B

BRACKET ASSY, SEAT, OUTER RH

71260

BRACKET ASSY, SEAT, OUTER LH

71293A

PLATE, REAR SEAT BACK, UPPER

71301D

HINGE SUB-ASSY, REAR SEAT, RH

71302D

HINGE SUB-ASSY, REAR SEAT, LH

71303C

HINGE SUB-ASSY, REAR SEAT BACK, RH

71304C

HINGE SUB-ASSY, REAR SEAT BACK, LH

71305A

HINGE SUB-ASSY, REAR SEAT BACK, CENTER

71393A

BAND, REAR SEAT CUSHION, RH

71393B

BAND, REAR SEAT CUSHION, LH

71460S

CUSHION ASSY, REAR SEAT, RH(FOR SEPARATE TYPE)

71470S

CUSHION ASSY, REAR SEAT, LH (FOR SEPARATE TYPE)

71480E

CLIP, REAR SEAT BACK, RH

71480S

BACK ASSY, REAR SEAT, RH (FOR SEPARATE TYPE)

71490A

CLIP, REAR SEAT BACK, LH

71490S

BACK ASSY, REAR SEAT, LH (FOR SEPARATE TYPE)

71611A

PAD, REAR SEAT CUSHION, RH

71612A

PAD, REAR SEAT CUSHION, LH

71651S

PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE)

71652S

PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE)

72601

STRIKER SUB-ASSY, REAR SEAT LOCK

72603

LOCK SUB-ASSY, REAR SEAT BACK, RH

72604

LOCK SUB-ASSY, REAR SEAT BACK, LH

72646

GROMMET, REAR SEAT BACK STOP BUTTON

72656

BUTTON, REAR SEAT BACK STOP RELEASE

72660A

SUPPORT ASSY, REAR SEAT CUSHION

72660D

SUPPORT ASSY, REAR SEAT CUSHION

72681

HOOK, REAR SEAT BACK LOCK, LOWER

72681C

HOOK, REAR SEAT BACK LOCK, LOWER

72694B

COVER, REAR SEAT CUSHION LOCK, RH

72694C

COVER, REAR SEAT CUSHION LOCK, LH

9008011157

Крепеж

9008046007

Крепеж

9010508274

Крепеж

9011906126

Крепеж

9011908240

Крепеж

9014980035

Крепеж

9015940071

Крепеж

9046818071

Крепеж

9151160612

Крепеж

9151380820

Крепеж

9163160612

Крепеж

9324955010

Крепеж

9354054014

Крепеж

Код

Описание

71015A

FRAME SUB-ASSY, REAR SEAT CUSHION, RH

71016A

FRAME SUB-ASSY, REAR SEAT CUSHION, LH

71017

FRAME SUB-ASSY, REAR SEAT BACK, RH

71018

FRAME SUB-ASSY, REAR SEAT BACK, LH

71075S

COVER, REAR SEAT CUSHION, RH (FOR SEPARATE TYPE)

71076S

COVER, REAR SEAT CUSHION, LH (FOR SEPARATE TYPE)

71077S

COVER, REAR SEAT BACK, RH (FOR SEPARATE TYPE)

71078S

COVER, REAR SEAT BACK, LH(FOR SEPARATE TYPE)

71250B

BRACKET ASSY, SEAT, OUTER RH

71260

BRACKET ASSY, SEAT, OUTER LH

71301D

HINGE SUB-ASSY, REAR SEAT, RH

71302D

HINGE SUB-ASSY, REAR SEAT, LH

71303C

HINGE SUB-ASSY, REAR SEAT BACK, RH

71304C

HINGE SUB-ASSY, REAR SEAT BACK, LH

71305A

HINGE SUB-ASSY, REAR SEAT BACK, CENTER

71393A

BAND, REAR SEAT CUSHION, RH

71393B

BAND, REAR SEAT CUSHION, LH

71460S

CUSHION ASSY, REAR SEAT, RH(FOR SEPARATE TYPE)

71470S

CUSHION ASSY, REAR SEAT, LH (FOR SEPARATE TYPE)

71480E

CLIP, REAR SEAT BACK, RH

71480S

BACK ASSY, REAR SEAT, RH (FOR SEPARATE TYPE)

71490A

CLIP, REAR SEAT BACK, LH

71490S

BACK ASSY, REAR SEAT, LH (FOR SEPARATE TYPE)

71611A

PAD, REAR SEAT CUSHION, RH

71612A

PAD, REAR SEAT CUSHION, LH

71651S

PAD, REAR SEAT BACK, RH(FOR SEPARATE TYPE)

71652S

PAD, REAR SEAT BACK, LH(FOR SEPARATE TYPE)

71931A

SUPPORT, REAR SEAT HEADREST

71940A

HEADREST ASSY, REAR SEAT

72601

STRIKER SUB-ASSY, REAR SEAT LOCK

72603

LOCK SUB-ASSY, REAR SEAT BACK, RH

72604

LOCK SUB-ASSY, REAR SEAT BACK, LH

72646

GROMMET, REAR SEAT BACK STOP BUTTON

72656

BUTTON, REAR SEAT BACK STOP RELEASE

72660A

SUPPORT ASSY, REAR SEAT CUSHION

72660D

SUPPORT ASSY, REAR SEAT CUSHION

72681

HOOK, REAR SEAT BACK LOCK, LOWER

72681C

HOOK, REAR SEAT BACK LOCK, LOWER

72694B

COVER, REAR SEAT CUSHION LOCK, RH

72694C

COVER, REAR SEAT CUSHION LOCK, LH

9008011157

Крепеж

9008046007

Крепеж

9010508274

Крепеж

9011906126

Крепеж

9011908240

Крепеж

9014980035

Крепеж

9015940071

Крепеж

9046818071

Крепеж

9151160612

Крепеж

9151380820

Крепеж

9163160612

Крепеж

9324955010

Крепеж

9354054014

Крепеж
