Каталог
Ближний ВостокМодель
CELICAДвигатель
2 литраКузов
POUNDSКласс
XT TYPEФрейм
RA40Трансмиссия
механика МКПП, 5 скоростейОпции
правый руль Европа Европа
Код
Описание
21015
HOUSING SUB-ASSY, COIL
21112
HORN, AIR
21192
BREAKER
21209
FLOAT SUB-ASSY
21301
VALVE SUB-ASSY, NEEDLE
21452
LEVER, PUMP
21471
LINK, PUMP CONNECTING
2153136110
Крепеж
21551
HOLDER, BACK SPRING
21618
GASKET, NEEDLE VALVE SEAT
21621
GASKET, UNION NIPPLE
21627
GASKET, COIL HOUSING
21699
BOOT(FOR PUMP PLUNGER)
21735
SPRING, PUMP ARM
21751
UNION, NIPPLE
21763
PIN, FLOAT LEVER
2176536120
Крепеж
21791
RING, SNAP, NO.1(FOR CARBURETOR LINK)
21799
RING, E, TOP
21811
BOLT, UNION NIPPLE
2183244051
Крепеж
2183436120
Крепеж
2184136120
Крепеж
2187536120
Крепеж
2187540040
Крепеж
Код
Описание
21077
COVER(FOR AUXILIARY ACCELERATION PUMP)
21077A
GASKET(FOR AUXILIARY ACCELERATION PUMP)
21077B
SPRING(FOR AUXILIARY ACCELERATION PUMP)
21077C
BALL, STEEL(FOR AUXILIARY ACCELERATION PUMP)
21077D
VALVE, CHECK(FOR AUXILIARY ACCELERATION PUMP)
21077E
SPRING(FOR AUXILIARY ACCELERATION PUMP COVER)
21129
COVER(FOR THERMOSTATIC VALVE)
21203
BLEEDER SUB-ASSY, 1ST MAIN AIR
21205
JET SUB-ASSY, SLOW
21211
VENTURI, 1ST SMALL
21212
VENTURI, 2ND SMALL
21249
JET, AIR BLEED, NO.2
21251
JET, 1ST MAIN
21253
JET, 2ND MAIN
21255
JET, POWER
21259
JET, AIR BLEED
21291
GLASS, LEVEL GAGE
21299
NET, PUMP FILTER
2130836110
Крепеж
21312
BALL, STEEL
21335
VALVE, THERMOSTATIC
21353
PLUNGER, PUMP
21449
LEVER, 2ND KICK
21456
LEVER, 1ST THROTTLE IDLE ADJUSTING, NO.1
21474
LINK, CONNECTING
21561
WEIGHT, PUMP DISCHARGE
21576
CLIP, PUMP STRAINER
21611
GASKET, MAIN JET
21612
GASKET, POWER VALVE
2161236110
Крепеж
21612A
GASKET, POWER JET
21614
GASKET, VENTURI
21617
GASKET, MAIN PASSAGE PLUG
21622
GASKET, AIR HORN
21625
GASKET, LEVEL GAGE
21631
GASKET, MAIN GUIDE
21641
GASKET(FOR THERMOSTATIC VALVE COVER)
21648
PACKING(FOR SLOW VALVE COVER)
21659
RING, O(FOR THERMOSTATIC VALVE)
21667
DIAPHRAGM
21722
SPRING, PUMP DAMPING
21736
SPRING, 1ST IDLE CAM
2176536120
Крепеж
2177636110
Крепеж
21781
PLUG, MAIN PASSAGE(FOR CARBURETOR JET)
21786
PLUG, PUMP PASSAGE
21787
PLUG, PUMP JET
21797
RING, SNAP, NO.4(FOR CARBURETOR LINK)
2179936120
Крепеж
2181636120
Крепеж
2181736120
Крепеж
2183236110
Крепеж
2183244120
Крепеж
2183436110
Крепеж
21842
SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)
2185236110
Крепеж
2187436120
Крепеж
2188136120
Крепеж
21934
SOLENOID, THROTTLE VALVE
Код
Описание
21113
FLANGE, CARBURETOR
21165
INSULATOR
21171
CHAMBER, DIAPHRAGM
21171A
DIAPHRAGM(FOR DIDPHRAGM CHAMBER)
21192A
HOSE, NO.1(FOR BREAKER)
21271
SCREW, IDLE ADJUSTING
21272
SCREW, 1ST IDLE ADJUSTING
21273
SCREW, THROTTLE ADJUSTING
21281
NOZZLE, IDLE
2133236120
Крепеж
21431
ARM, 1ST THROTTLE SHAFT
21453
LEVER, 1ST THROTTLE
21461
LEVER, 1ST IDLE
21463
LEVER, 2ND THROTTLE
21557
SPACER(FOR 1ST IDLE CAM)
21629
GASKET, IDLE NOZZLE
21634
GASKET, SLOW PASSAGE PLUG
21645
GASKET, DIAPHRAGM, CAP
21672
CAP
21723
SPRING, IDLE ADJUSTING
21724
SPRING, THROTTLE ADJUSTING
21726
SPRING, 1ST IDLE ADJUSTING
21728
SPRING, THROTTLE VALVE RETURN
21756
SPRING, BACK(FOR THROTTLE SHAFT)
21784
PLUG, SLOW PASSAGE
21797
RING, SNAP, NO.4(FOR CARBURETOR LINK)
2182936120
Крепеж
2183244051
Крепеж
21833
SCREW, SET, NO.1(FOR CARBURETOR BODY SET)
2184536120
Крепеж
21852
NUT, THROTTLE LEVER SET
21867
SPRING, DIAPHRAGM
2187436120
Крепеж
21881
WASHER, LOCK(FOR THROTTLE SHAFT)
Код
Описание
21015
HOUSING SUB-ASSY, COIL
21077
COVER(FOR AUXILIARY ACCELERATION PUMP)
21077A
GASKET(FOR AUXILIARY ACCELERATION PUMP)
21077B
SPRING(FOR AUXILIARY ACCELERATION PUMP)
21077C
BALL, STEEL(FOR AUXILIARY ACCELERATION PUMP)
21077D
VALVE, CHECK(FOR AUXILIARY ACCELERATION PUMP)
21077E
SPRING(FOR AUXILIARY ACCELERATION PUMP COVER)
21112
HORN, AIR
21165
INSULATOR
21171
CHAMBER, DIAPHRAGM
21171A
DIAPHRAGM(FOR DIDPHRAGM CHAMBER)
21192
BREAKER
21192A
HOSE, NO.1(FOR BREAKER)
21193
BREAKER, 1ST IDLE CAM
21203
BLEEDER SUB-ASSY, 1ST MAIN AIR
21205
JET SUB-ASSY, SLOW
21209
FLOAT SUB-ASSY
21249
JET, AIR BLEED, NO.2
21251
JET, 1ST MAIN
21253
JET, 2ND MAIN
21255
JET, POWER
21259
JET, AIR BLEED
21271
SCREW, IDLE ADJUSTING
21272
SCREW, 1ST IDLE ADJUSTING
21273
SCREW, THROTTLE ADJUSTING
21281
NOZZLE, IDLE
21291
GLASS, LEVEL GAGE
21299
NET, PUMP FILTER
21301
VALVE SUB-ASSY, NEEDLE
2130836110
Крепеж
21312
BALL, STEEL
21335
VALVE, THERMOSTATIC
21353
PLUNGER, PUMP
2153136110
Крепеж
21551
HOLDER, BACK SPRING
21561
WEIGHT, PUMP DISCHARGE
21576
CLIP, PUMP STRAINER
21611
GASKET, MAIN JET
21612
GASKET, POWER VALVE
2161236110
Крепеж
21614
GASKET, VENTURI
21617
GASKET, MAIN PASSAGE PLUG
21618
GASKET, NEEDLE VALVE SEAT
21621
GASKET, UNION NIPPLE
21622
GASKET, AIR HORN
21625
GASKET, LEVEL GAGE
21627
GASKET, COIL HOUSING
21629
GASKET, IDLE NOZZLE
21631
GASKET, MAIN GUIDE
21634
GASKET, SLOW PASSAGE PLUG
21641
GASKET(FOR THERMOSTATIC VALVE COVER)
21645
GASKET, DIAPHRAGM, CAP
21648
PACKING(FOR SLOW VALVE COVER)
21659
RING, O(FOR THERMOSTATIC VALVE)
21667
DIAPHRAGM
21672
CAP
21679
POSITIONER
21699
BOOT(FOR PUMP PLUNGER)
21722
SPRING, PUMP DAMPING
21723
SPRING, IDLE ADJUSTING
21724
SPRING, THROTTLE ADJUSTING
21726
SPRING, 1ST IDLE ADJUSTING
21735
SPRING, PUMP ARM
21736
SPRING, 1ST IDLE CAM
21751
UNION, NIPPLE
21756
SPRING, BACK(FOR THROTTLE SHAFT)
21763
PIN, FLOAT LEVER
2176536120
Крепеж
2177636110
Крепеж
21781
PLUG, MAIN PASSAGE(FOR CARBURETOR JET)
21784
PLUG, SLOW PASSAGE
21786
PLUG, PUMP PASSAGE
21787
PLUG, PUMP JET
21791
RING, SNAP, NO.1(FOR CARBURETOR LINK)
21797
RING, SNAP, NO.4(FOR CARBURETOR LINK)
21799
RING, E, TOP
2179936110
Крепеж
2180434590
Крепеж
21811
BOLT, UNION NIPPLE
2181636120
Крепеж
2181736120
Крепеж
2182936120
Крепеж
2183236110
Крепеж
2183244051
Крепеж
2183244120
Крепеж
21833
SCREW, SET, NO.1(FOR CARBURETOR BODY SET)
2183334590
Крепеж
2183436110
Крепеж
2183436120
Крепеж
2184136120
Крепеж
21842
SCREW, SET(FOR CARBURETOR LEVEL GAGE CLAMP SET)
2184536120
Крепеж
21852
NUT, THROTTLE LEVER SET
2185236110
Крепеж
2187436120
Крепеж
2187536120
Крепеж
2187540040
Крепеж
21881
WASHER, LOCK(FOR THROTTLE SHAFT)
2188136120
Крепеж
21934
SOLENOID, THROTTLE VALVE
