TRANSFER VALVE BODY & VALVE LEVER TOYOTA 4-RUNNER TRUCK (JPP), 1988/08 - 1989/08, 3 литра, EFI, LOW DECK (STANDARD DECK), SR-5 TYPE,GLX TYPE, VZN110, автомат, АКПП, 4 ступени

Каталог

Европа

Модель

4-RUNNER TRUCK (JPP)

Двигатель

3 литра, EFI

Кузов

LOW DECK (STANDARD DECK)

Класс

SR-5 TYPE,GLX TYPE

Фрейм

VZN110

Трансмиссия

автомат АКПП, 4 ступени

Опции

EXTRA CAB электронная система впрыска топлива США IV3 JPP

Код

Описание

34409

SPRING SUB-ASSY, TRANSFER MANUAL DETENT

34410A

STRAINER, OIL (FOR TRANSFER VALVE BODY)

34432

PLATE, TRANSFER VALVE BODY, UPPER

34433

GASKET, TRANSFER UPPER VALVE BODY, NO.1

34434

GASKET, TRANSFER UPPER VALVE BODY, NO.2

34435

PLATE, TRANSFER VALVE BODY, LOWER

34436

GASKET, TRANSFER LOWER VALVE BODY, NO.1

34437

GASKET, TRANSFER LOWER VALVE BODY, NO.2

34471

COVER, LOW SPEED BRAKE ACCUMULATOR

34471A

RING, O (FOR LOW SPEED BRAKE ACCUMULATOR COVER)

34480A

BALL (FOR TRANSFER UPPER VALVE BODY)

34550

LEVER ASSY, TRANSFER MANUAL VALVE

34550A

PIN, SLOTTED SPRING (FOR TRANSFER MANUAL VALVE LEVER)

34550B

SPACER (FOR TRANSFER MANUAL VALVE LEVER)

34561

SHAFT, TRANSFER MANUAL VALVE LEVER

34561A

SEAL, OIL (FOR TRANSFER MANUAL VALVE LEVER SHAFT)

34599

COVER, TRANSFER MANUAL DETENT SPRING

35421K

PISTON, ACCUMULATOR, NO.1

35421L

RING, O (FOR ACCUMULATOR, NO.1 PISTON INNER)

35421M

RING, O (F0R ACCUMULATOR, NO.1 PISTON OUTER)

35421N

SPRING, COMPRESSION (FOR ACCUMULATOR, NO.1 PISTON)

35574A

LEVER, TRANSFER CONTROL SHAFT

8410

переход к группе запчастей

9010505001

Крепеж

9010505003

Крепеж

9010505005

Крепеж

9010505009

Крепеж

9010505010

Крепеж

9010505014

Крепеж

9010506015

Крепеж

9010506017

Крепеж

9010506020

Крепеж

9010506026

Крепеж

9010506049

Крепеж

9411040800

Крепеж

9451200800

Крепеж

Код

Описание

34418

VALVE, TRANSFER MANUAL

34430

BODY ASSY, TRANSFER LOWER VALVE, NO.1

34441

VALVE, LOW-HIGH SHIFT CONTROL

34442

VALVE, LOW-HIGH SHIFT

34442A

SPRING, COMPRESSION(FOR LOW-HIGH SHIFT VALVE)

34443

PLUG, LOW-HIGH SHIFT VALVE

34443A

KEY, STRAIGHT(FOR LOW-HIGH SHIFT VALVE PLUG)

34444

VALVE, LOW-HIGH SHIFT TIMING

34444A

SPRING, COMPRESSION(FOR LOW-HIGH SHIFT TIMING VALVE)

34445

PLUG, LOW-HIGH SHIFT TIMING VALVE

34445A

SEAT(FOR LOW-HIGH SHIFT TIMING VALVE PLUG)

34446

VALVE, LOW-HIGH SIGNAL

34446A

SPRING, COMPRESSION(FOR LOW-HIGH SIGNAL VALVE)

34447

PLUG, LOW-HIGH SIGNAL VALVE

34447A

SEAT(FOR LOW-HIGH SIGNAL VALVE PLUG)

34448

VALVE, LOW-HIGH SIGNAL CONTROL

34452

VALVE, TRANSFER DIRECT CLUTCH MODULATOR

34452A

SPRING (FOR TRANSFER DIRECT CLUTCH MODULATOR VALVE)

34453

PLUG, DIRECT CLUTCH MODULATOR VALVE

34453A

SEAT (FOR DIRECT CLUTCH MODULATOR VALVE PLUG)

34454

VALVE, TRANSFER DIRECT CLUTCH ACCUMULATOR

34454A

SPRING (FOR TRANSFER CLUTCH ACCUMULATOR VALVE)

34455

PLUG, TRANSFER DIRECT CLUTCH ACCUMULATOR

34455A

KEY (FOR TRANSFER DIRECT CLUTCH ACCUMULATOR PLUG

34460

BODY ASSY, TRANSFER LOWER VALVE, NO.2

34462

VALVE, HIGH-LOW ORIFICE CONTROL

34462A

SPRING, COMPRESSION(FOR HIGH-LOW ORIFICE CONTROL VALVE)

34463

PLUG, HIGH-LOW ORIFICE CONTROL VALVE

34463A

SEAT(FOR HIGH-LOW ORIFICE CONTROL VALVE PLUG)

34480

BODY ASSY, TRANSFER UPPER VALVE
